  2. MECHANICAL INFRASTRUCTURE

Academic Labs:

S.No Name of the Laborarory Name of the Important Equipment Area in Sq.Mts
1 Engineering workshop
  1. Universal wood turning machine, Carpentry turning lathe – 2Nos, 7” heavy vices – 13no’s, 9” light vices -8 Nos, 6” light vices -3 Nos.
  2. Pillar type Drilling machine – 1 No., bench grinder – 1 No., Power press – 1 No., 6” bench vices -16 Nos., 4” bench vices -7 Nos.
  3. Hand operating stake machine, Stakes – 16 Nos., Hand operating pipe bending machine – 1 No., Hand operating circular machine -1 No., Hand operating pressing machine -1 No.
  4. House wiring panel boards – 2 Nos.
  5. Furnaces with hand blowers – 2 Nos., swage blocks, anvils.
 414.61
2 Mechanical Engineering Lab
  1. Redwood Viscometers –I & II,
  2. Saybolt’s Apparatus,
  3. Pensky Martins flash point Apparatus,
  4. Clevelands open cup Apparatus,
  5. Pressure gauge setup,
  6. Carbon Residue test,
  7. 4-Stroke Diesel Engine for Valve Timing Diagram,
  8. 2-Stroke Petrol Engine for Port Timing Diagram ,
  9. Fly Wheel setup for MI calculation,
  10. Compound Pendulum,
  11. Torsional pendulum.
 75.92
3 Manufacturing Process Lab
  1. Machine Lathes-19 No's,
  2. HMT Lathe- 1 No.,
  3. Capstan Lathe-1 No.,
  4. Milling Machine-1No.,
  5. Arc Welding Equipment,
  6. Foundry Equipment,
  7. Hydraulic Power Hacksaws-2No's,
  8. Shaping Machine- 1 No.,
  9. Planer Machine- 1No.
 367.36
4 Strength of Materials Lab
  1. Universal Testing Machine,
  2. Rockwell hardness tester,
  3. Brinell and Vickers hardness tester,
  4. Impact testing machine,
  5. Torsion testing machine,
  6. Spring testing machine.
 136.33
5 ICE & KOM Lab
  1. Single cylinder, 6 HP Diesel Engine With Belt Brake dynamometer.
  2. Single Cylinder, 5 HP Diesel Engines -2 (Coupled with Hydraulic Brake Dynometer/ DC Generator).
  3. Single Cylinder, 6 HP Diesel Engine With Rope Brake dynamometer.
  4. Twin Cylinder, 10 HP Diesel Engine with Hydraulic Brake Dynometer.
  5. Two Stage Reciprocating Air Compressor,
  6. Single Cylinder, Two Stroke 4 HP Diesel Engine.
  7. Motorised Gyroscope setup.
  8. Static & Dynamic balance test equipment
  9. Centrifugal water pump with 4 HP Motor.
  10. I.C Engine Components.
  11. Computer Based Single Cylinder, four-stroke VCR Multi Fuel engine (both Petrol and Diesel) with open ECU for Petrol mode.
  12. Computer Based Multi Cylinder Petrol Engine Test Rig.
  13. Gas Analyser for measuring (CO, HC, CO2, O2, NO2 & SO2) with standard accessories, software and 24- column dot matrix printer.
  14. Diesel smoke meter with standard accessories, Software and 24-column dot matrix printer.
  15. Launch X- 431pro (Cars diagnostic scan apparatus)
 339.23
6 Machine Tools Lab
  1. Universal Milling machine,
  2. Shaping machine,
  3. Surface grinding machine,
  4. Surface roughness tester,
  5. Slotting machine,
  6. Sieve shaker,
  7. All cut machine,
  8. Tool and Cutter Grinder,
  9. All geared bench Drilling machine,
  10. Rapid moisture teller,
  11. Clay content testing machine,
  12. Universal compression strength machine,
  13. Hardness tester,
  14. Sand rammers,
  15. Weighing machine (Mechanical and Electrical).
 392.78
7 Metrology Lab.
  1. Vernier calipers-11No's,
  2. Slip gauge set-2No's,
  3. C.I Surface plate,
  4. Angle Plates-2No's,
  5. Granite surface plate,
  6. Dial gauges-4No's,
  7. Outside micrometers-4No's,
  8. Compact Tool makers Micro Scopes-2No's,
  9. Thread ring gauge set-1No.,
  10. Optical bevel protractors-2No's,
  11. Five channel digital strain gauge meters 2No's,
  12. Indicating micrometer -1No.,
  13. Surface roughness indicators-2No's,
  14. Electronic comparators - 2No's,
  15. Profile projectors - 2No's.
 75.15
8 Industrial Engineering Lab.
  1. Bicycle Ergo meter,
  2. Tread mill,
  3. Electric toasters -2 No’s,
  4. B.P Apparatus,
  5. Weighing Machine,
  6. Vernier Calipers -2 No’s,
  7. Plain plug Gauge,
  8. Stopwatches-13 No's,
  9. Stethoscopes -3No's.
 93.09
9 Fluid Mechanics Lab
  1. Pelton turbine test rig
  2. Pipe friction apparatus
  3. Bernoulli’s apparatus- 1No’s
  4. Notches ( V-Rectangular, trapezoidal)-1No’s
  5. Venturi meter
  6. Orifice meter
  7. Pitot Tube
  8. Reciprocating Pump test rig
  9. Centrifugal pump test rig
  10. Impact of jet setup
 104.04
10 Heat Transfer Lab
  1. Thermal Conductivity of metal Bar Apparatus
  2. Composit wall Apparatus
  3. Pin Fin Apparatus
  4. Natural convection on vertical bar Apparatus
  5. Stefan Boltzman's Apparatus
  6. Emissivity measurement Apparatus
  7. Parallel and Counter flow Apparatus
  8. Drop and Film Wise Condensation phenomenon setup
  9. Forced Convection Apparatus
  10. Two Phase heat Transfer Apparatus
  11. Refrigeration test rig
  12. Air Conditioning Text Rig
 75.56
11 CAD Lab
  1. Computer systems :88 No's,
  2. UPS : 10KVA UPS,
  3. Auto CAD : Free student version,
  4. Solid works:100 user,
  5. Pro-E Wild Fire 3 - 5 users,
  6. CATIA V5- 5 users.
 140.27
12 CAM Lab
  1. Computer systems - 2 No's,
  2. CNC Turning machine-1 No.,
  3. CNC Vertical Milling machine-1 No.,
  4. Hetero fitted Turning machine- 1 No’s
  5. CMAS Software - 5 users.
 15.41

Research Laboratories:

S. No Laboratory Equipment list Utilization/Purpose Area in Sq. Mt
1 Centre for Metal Matrix Composite
  1. Rotary Fatigue testing machine
  2. Electrical resistance furnace
 Utilized by UG, PG and PhD Students for conducting Fatigue tests and the fabrication of composites using liquid metallurgy route. 14.26
2 Centre for collaborative product development
  1. Coordinate measuring machine
  2. 3D Printer
  3. CAD Station
 Utilized by UG, PG and PhD Students for measuring the co-ordinates of complex profiles, fabrication of parts using fused deposition modelling and Design the models. 35.92
3 Development of multilayer thin film sensor for practical monitoring of weld stress
  1. Thermo Mechanical Strain gauge tester
  2. Micro Resistance Meter
 Utilized by UG, PG and PhD Students for measuring of strain in thermal environment. 15.33
4 APPSC (Dassault Systems Lab)
  1. Laptops :36 No's
  2. 3-D Experiences Soft Ware-Provided by Dassault Systems
 Utilized by UG, PG and PhD Students are Trained the 3-D Experiences Software. 96.68
5 MODROBS (Modernisation and Removal of Obsolescence)
  1. Computer Based Single Cylinder four stroke VCR Multi Fuel engine (both Petrol and Diesel) with open ECU for Petrol mode.
  2. Computer Based Multi Cylinder Petrol Engine Test.
  3. Gas Analyser for measuring (CO, HC, CO2, O2, NO & SO2) with standard accessories, software and 24- column dot matrix printer.
  4. Diesel smoke meter with standard accessories, Software and 24-column dot matrix printer.
 Utilized by UG, PG and PhD Students for conducting various tests on alternate fuels 28.8
